P/N PS-SPD-0650MNFABx-1
WATTS 650W
RGB FAN No
MODEL SP-650AH3CCB-B
TYPE ATX 12V v2.4 and EPS v2.92
MAX. OUTPUT CAPACITY 650W
PEAK OUTPUT CAPACITY 780W
COLOR Black
DIMENSION ( W / H / D ) 150mm(W) x 86mm(H) x 160mm(D)
PFC (POWER FACTOR CORRECTION) Active PFC
POWER GOOD SIGNAL 100-500 msec
HOLD UP TIME > 12msec at 80% of full load at 230Vac input
INPUT CURRENT 10A max.
INPUT FREQUENCY RANGE 47Hz -63Hz
INPUT VOLTAGE 100V-240V~
OPERATING TEMPERATURE 0°C to +40°C
OPERATING HUMIDITY 20% to 90%,non-condensing
STORAGE TEMPERATURE -20 °C to +70 °C
STORAGE HUMIDITY 5% to 95%, non-condensing
COOLING SYSTEM 140mm Fan: 2300 R.P.M. ± 10%
EFFICIENCY Meet 80 PLUS®Bronze at 115Vac input.
MTBF 100,000 hrs minimum
SAFETY APPROVAL cTUVus/TUV/CE/FCC/S-mark/EAC/BSMI/C-TICK/CCC
PCI-E 6+2PIN 4
PROTECTION OVP ,OPP, OCP, OTP
