Descripción
Product Number
MAM-D6PN-120PA-R1
CPU Socket
LGA2066, LGA2011-v3, LGA2011, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
Dimensions (L x W x H)
135 x 125 x 165 mm / 5.3 x 4.9 x 6.5 inch
Heat Sink Material
6 Heat Pipes, Aluminum Fins
Fan Dimensions (L x W x H)
120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch
Fan Quantity
1 PCS
Fan Speed
650-2000 RPM (PWM) ± 10%
Fan Airflow
57.3 CFM (Max)
Fan Air Pressure
2.0 mmH2O (Max)
Fan MTTF
160,000 Hours
Fan Noise Level
8 - 30 dBA
Fan Power Connector
4-Pin (PWM)
Fan Rated Voltage
12VDC
Fan Rated Current
0.16A
Fan Safety Current
0.37A
Fan Power Consumption
1.92W
Warranty
5 years
Series
MasterAir
Cooler Type
Air Cooler
Heatpipes
6
