Descripción
Modular
Fully Modular
PFC
Active PFC
Input Frequency
50-60Hz
ErP 2014 Lot 3
Yes
ATX 24 Pin Connectors
1
EPS 4+4 Pin Connectors
1
EPS 8 Pin Connector
1
Fan Bearing
FDB
Fan Size
92mm
LAMBDA Rating
Standard+
80 PLUS Rating
80 PLUS Gold
Power Good Signal
100 - 500 ms
MTBF
>100,000 Hours
Category
500 to 750W
80 Plus
Gold
ETA Rating
Gold
Operating Temperature
0-50°C
Input Voltage
100-240V
SATA Connectors
8
PCI-e 6+2 Pin Connectors
4
Peripheral 4 Pin Connectors
4
Dimensions (L x W x H)
100 x 125 x 63.5 mm
Efficiency
90% @ Typical Load
Protections
OVP
Protections
OPP
Protections
SCP
ATX Version
SFX 12V Ver. 3.42
Protections
UVP
Hold Up Time
16ms
Protections
OTP
Protections
OCP
Series
V SFX Series
Protections
Surge and Inrush Protection
Regulatory
CCC
Input Current
10-5A
Regulatory
CE
Regulatory
RCM
Regulatory
EAC
Regulatory
cTUVus
Regulatory
FCC
Regulatory
BSMI
Regulatory
CB
Regulatory
TUV
Regulatory
KCC
Regulatory
UKCA
Model
MPY-7501-SFHAGV
