Descripción
Applicable CPU(s)
AMD Socket FM2/FM1/AM3+/AM3/AM2+/AM2/AM4/940/939/754
INTEL Socket LGA1200/115X/LGA775/LGA1366
TDP 135W Recommend (< 180W)
Technical Parameter
Overall Dimension 125*125*83MM
Fan Dimension 120*120*25MM
Net Weight 640g
Connector of Fan 4PIN PWM
RGB of Fan 3PIN Aura header
Rated Voltage 12VDC
Operating Voltage 10.8~13.2VDC
Starting Voltage 8V(ON/OFF)
INPUT CURRENT 0.22A (MAX0.45A)
Locked current 0.04A
Power Input 2.64W(Max 5.4W)
FAN PWM Speed 800-1900RPM±10%
MAX.Air Flow 21-58.8CFM
Maximum Air Pressure 2.18mmH2O
Noise 17.5-28.8dB(A)
Bearing Type Dynamic Hydro Bearing
INSULATION TYPE CLASS A
Net Weight 640g
