Descripción
Product Number
MAM-D6PS-314PK-R1
Exterior Color
Black
CPU Socket
LGA2066, LGA2011-v3, LGA2011, LGA1200, LGA1366, LGA1156, LGA1155, LGA1151, LGA1150, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1
Dimensions (L x W x H)
144.9 x 153.2 x 160 mm / 5.7 x 6 x 6.3 inch
Heat Sink Material
6 Heat Pipes, Aluminum Fins
Fan Dimensions (L x W x H)
140 mm Fan - 140 x 140 x 25 mm / 5.5 x 5.5 x 1 inch, 120 mm Fan - 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch
Fan Quantity
140 mm Fan - 2 PCS, 120 mm Fan - 1 PC
Fan Speed
140 mm Fan - 650-1400 RPM (PWM) ± 5%, 120 mm Fan - 650-1800 RPM (PWM) ± 5%
Fan Airflow
140 mm Fan - 67 CFM (Max), 120 mm Fan - 62 CFM (Max)
Fan Noise Level
140 mm Fan - 10 ~ 27 dBA, 120 mm Fan - 8 ~ 27 dBA
Fan Air Pressure
140 mm Fan - 2.25 mmH2O (Max), 120 mm Fan - 2.5 mmH2O (Max)
Fan MTTF
160,000 Hours
Fan Power Connector
4-Pin (PWM)
Fan Rated Voltage
12VDC
Fan Rated Current
0.15A
Fan Safety Current
140 mm Fan - 0.4A, 120 mm Fan - 0.37A
Fan Power Consumption
1.8W
Warranty
5 years
Series
MasterAir
Cooler Type
Air Cooler
Heatpipes
6
