PERFORMANCE
Processor Intel® Core™ i5-1235U, 10C (2P + 8E) / 12T, P-core 1.3 / 4.4GHz, E-core 0.9 / 3.3GHz, 12MB
Graphics Integrated Intel® Iris® Xe Graphics Functions as UHD Graphics
Chipset Intel® SoC Platform
Memory 8GB Soldered DDR4-3200
Memory Slots One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
Max Memory Up to 16GB (8GB soldered + 8GB SO-DIMM) DDR4-3200 offering
Storage 256GB SSD M.2 2242 PCIe® 4.0x4 NVMe® + Empty HDD Bay
Storage Support Models with 38Wh battery: up to two drives, 1x 2.5" HDD + 1x M.2 SSD
• 2.5" HDD up to 1TB
• M.2 2242 SSD up to 512GB
Storage Slot Models with 38Wh battery: one 2.5" drive slot + one M.2 slot
• One 2.5" SATA HDD slot
• One M.2 2280 PCIe® 4.0 x4 slot
Card Reader None
Optical None
Audio Chip High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers Stereo speakers, 1.5W x2, Dolby® Audio™
Camera HD 720p with Privacy Shutter
Microphone 2x, Array
Battery Integrated 38Wh
Max Battery Life Models with 38Wh battery:
MobileMark® 2018: 5.3 hr
Local video (1080p) playback@150nits: 6.85 hr
Power Adapter 65W Round Tip (3-pin)
DESIGN
Display 15.6" FHD (1920x1080) TN 250nits Anti-glare
Touchscreen None
Keyboard Non-backlit, Spanish (LA)
Case Color Iron Grey
Surface Treatment IMR (In-Mold Decoration by Roller)
Case Material PC-ABS (Top), PC-ABS (Bottom)
Dimensions (WxDxH) 359 x 236 x 19.9 mm
Weight Starting at 1.7 kg
SOFTWARE
Operating System None
Bundled Software None
CONNECTIVITY
Ethernet 100/1000M (RJ-45)
WLAN + Bluetooth Wi-Fi® 6, 11ax 2x2 + BT5.1
Standard Ports
1x USB 2.0
1x USB 3.2 Gen 1
1x USB-C® 3.2 Gen 1 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.2)
1x HDMI® 1.4b
1x Ethernet (RJ-45)
1x Headphone / microphone combo jack (3.5mm)
1x Power connector
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader None
Physical Locks Kensington® Nano Security Slot™, 2.5 x 6 mm
Other Security Camera privacy shutter
