CPU (Max Support) i9
Socket 1700
Chipset Intel® B660 Chipset
DDR4 Memory 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz
Memory Channel Dual
DIMM Slots 4
Max Memory (GB) 128
PCI-E x16 2
PCI-E x1 1
SATAIII 6
M.2 Slot 2
RAID 0/1/5/10
LAN 1x Realtek® 8125BG 2.5G LAN
USB 3.2 ports (Front) 1(Gen 2, Type C), 2(Gen 1, Type A)
USB 3.2 ports (Rear) 1(Gen 2x2, Type C), 3(Gen 2, Type A)
USB 2.0 ports (Front) 4
USB 2.0 ports (Rear) 4
Audio ports (Rear) Realtek® ALC1200
DisplayPort 1
HDMI 1
DirectX 12
Form Factor mATX
CrossFire Y
Operating System Support for Windows® 11 64-bit, Windows® 10 64-bit
