Dust Filters Top, Front, Bottom
Radiator Support - Rear 120mm
Materials Steel, Mesh, Plastic, Tempered Glass
Pre-installed Fans - Top N/A
2.5" / 3.5" Drive Bays (combo) 2
5.25" Drive Bays 0
Warranty 2 years
Series MasterBox Series
Available Color(s) Black
Size Mid Tower
Clearance - PSU 180mm/7.08", 295mm/11.61" (w/ HDD cage removed)
Power Supply Support ATX
Fan Support - Rear 1x 120mm
Expansion Slots 7
Volume 51.87L (exlc. Protrusions)
Radiator Support - Front 120mm, 140mm, 240mm, 280mm, 360mm
Radiator Support - Top 120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)
Fan Support - Front 3x 120mm, 2x 140mm
Clearance - CPU Cooler 165mm/6.49"
Motherboard Support Mini ITX, Micro ATX, ATX, E-ATX*, (*up to 12� x 10.7� motherboards, may impact cable management feature)
Fan Support - Top 3x 120mm, 2x 140mm
Pre-installed Fans - Rear 1x 120mm 650~1800RPM SickleFlow PWM ARGB
I/O Panel 2x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button
Pre-installed Fans - Front N/A
Clearance - GFX 410mm/16.1"
2.5" Drive Bays 4
Dimensions (L x W x H) 499.3 x 208.6 x 498mm (incl. Protrusions), 488.3 x 208.6 x 498mm (excl. Protrusions)
Model Number MB540-KGNN-S00
